Sargent Flexible Solar Panel

Sargent Flexible Solar Panel

Please select option to view code

MPN: SF100

Sargent Flexible Solar Panels

pdf More Information

available Available

Log in to view prices

Product Description

Sargent Flexible Panels

The SFlex range of soloar panels are ideally suited to leisure applications, with their low profile and flexible construction.

Output power available in 100watts (20049) and 160watts (20082)
Robust multi-layer construction- with ETFE coating
Up to 20 degree flexibility- for mounting onto curved surfaces.
50-60% weight saving- compared to metal framed panels
Wafer thin 2mm profile- provides discrete filment with low drag
LED power indicator- confirms panel is producing energy



20049 100W :-
Peak Power - 100W
Voltage (VMP) - 20.0V
Current (IMP) - 5.3A
O/C Voltage (VOC) - 24.0V
S/C Current (ISC) - 5.60A
Cell Efficiency - 22.0%
Max Flex Angle - 20 degree
Dimensions - 912mm x680xx
Weight - 1.7kg
Cable Length - 1.5metres

20082 160W :-
Peak Power - 160W
Voltage (VMP) - 16.5V
Current (IMP) - 10.6A
O/C Voltage (VOC) - 19.5V
S/C Current (ISC) - 10.8A
Cell Efficiency - 22.0%
Max Flex Angle - 20 degree
Dimensions - 680mm x1380xx
Weight - 2.5kg
Cable Length - 1.5metres
